Quadriceps Exercise Table

Nirmal-Quadriceps Table with One Torque unit is designed with Backrest for effective administration of progressive resistance exercises to the Knee joints muscle groups. Both QUADRICEPS & HAMSTRINGS can be exercised without changing the position of the patient.  Also useful for Shoulder and Elbow exercises.

SPECIFICATIONS:
* Torque Units: ONE set, (for Left OR Right Leg). Resistance Arms is calibrated so that resistance can be varied from  Minimum, 1/2, 3/4 & Maximum without adding weights, the unit consists two lever arms, one of which hold the  Weights while the other arm with shin foam roller provides contact with the patient's leg.
* Goniometry: A degree scale is provided on the torque unit to measure and record the range of motion from either Direction.
* Seat & Armrests: Fixed height, Foam padded Seat is fitted with adjustable Arm-rests.
* Backrest: Foam padded back can be positioned from vertically to horizontally for more exercise options.
* Stabilizing Straps: Provided with torso & thigh straps for patient safety.
* Resistance: By changing angle between the two arms, maximum or minimum resistance can be given without adding Weight.
* Weight Plates: 2 of 0.5kg each, & 5 of 1kg each. Total weight 06 kgs.
* Size: 70cm x 80cm x 135cm high.
* Finish: Frame, with Powder coated finished.
 :Torque Unit & working parts with Chrome plated finish.
